Flash Streaming 150kw Spin Flash Dryer

high recovery ratio Rotating and flash streaming drier with swirler

Descriptions

high recovery ratio Rotating and flash streaming drier with swirleris a new and high-efficiency drying equipment which is researched and developed for the sake of overcoming the low-efficiency and high energy-consuming of static drying. In its design, we have developed advantages and reduced shortcomings of common dryers, to realize the target of the consuming and high efficiency drying..

roduct Characteristics:

Feature

1. Drying viscous materials: The lower part of the drier is cone structure with a broken device together with the washing of wall by the air flow, which can handle a certain viscous materials. According to different materials, the feeder and discharger can take different forms, can be achieved the requirements of automatic and continuous feeding and smooth out of the material.

2. Drying heat-sensitive materials: Due to the short drying time, the relative speed of the materials and the hot air is large, and the hottest air not direct contact with the dried material. It can be used to deal with heat-sensitive materials.

3. Drying strength: The materials in the drying process have been broken, scoured, impacted, that increasing the surface area. At the same time, the hottest air hasn’t direct contact with the dried materials; therefore the inlet temperature can be higher than the melting point of materials. The higher of the inlet temperature equal to the more intensity of the drying equipment.

4. Effective controlling of the moisture and end fineness of the materials: Through the inside settings of the drier (swirl films, elutriate ring or screener), and coordinating with the inlet air temperature, can effectively controlled the moisture and end fineness of the materials.

aterial to be dried:

Application

1. Inorganic: cryolite, ultra-fine calcium carbonate, tellurium dioxide, manganese dioxide, sodium fluoride, kaolin, zirconium silicate, aluminum silicate,sodium thiosulfate, zinc sulfide, sulfate, cuprous chloride, calcium hypochlorite, boric acid, borax, hydroxide, light magnesium carbonate,iron oxide, quartz sand, titanium dioxide, iron oxide red, antimony oxide.

2. Organic: amino-anthraquinone, benzoic acid, sodium oxalate, long-chain dicarboxylic acid, lead acetate, hydroquinone, anthraquinone, sodium dichloroisocyanurate, Calcium Pantothenate, cyclohexanone, o-methyl benzoic acid, calcium citrate, sodium trichloroisocyanuric acid, sodium salicylate.

3. Polymers: PE, powdered styrene-butadiene rubber, sulfonated phenolic resins, polyvinyl chloride resins, polyvinyl acetate.

4. Dyes and Pigments: indigo, lead chromate, strontium chromate,yellow alkaline, medium black, lemon yellow, phthalocyanine blue, iron oxide black, iron oxide yellow, a neutral black.

5. Medicine: Amidopyrine, protein powder, nucleotide, guanosine.

6. Pesticides: atrazine, Abamectin, Bataan, chlorothalonil, mefenacet pyridaben, imidacloprid, glyphosate, mancozeb, paclobutrazol, fenoxaprop, Dan sterilization, insecticide Dan, monosultap, Bisultap, triphenyltin acetate, mites sweep net, Tricyclazole, double Gan phosphine.

7. Chemical Agents: white carbon black, to promote the agent D, accelerator TMTD, molecular sieve, activated clay, TBSI CZ, TBSI DM, TBSI M, TBSI TMTD, TBSI ZDC, phosphate Dibasic Lead acid, stearic acid salt.

8. Food and feed additives: Soy Protein Isolate, methionine chelate copper, starch, yeast powder, glucose.

Technical parameters

Dimension

Note: all details above for reference only. Because of material features, the parameters vary. we have the right to change but not notice, pardon!
