| Place of Origin: | CHINA |
|---|---|
| Brand Name: | YIGAN |
| Certification: | CE,GMP |
| Model Number: | SYH |
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Packaging Details: | Packed in film firstly, and then reinforced with wooden case for outer packing |
| Delivery Time: | 20 working days after received your payment |
| Supply Ability: | 30sets per month |
| Product Name: | Powder Blender/industrial Powder Mixer | Rotating Mode: | Planetary |
|---|---|---|---|
| Standard: | Pharmaceutical | Inside Surface: | Mirror Surface |
| Speed Adjust Mode: | By Transducer | Layout Type: | Horizontal |
| High Light: | 7.5kW powder blending machine,Horizontal Planetary Mixer Machine |
||
pharmaceutical use mirror surface planet motion powder blender
Mirror Surface Planet Motion Planetary Mixer Machine / Pharmaceutical Powder Mixer
Description
The mixing barrel moves in multi-directions. Materials have no centrifugal force effect, specific gravity segregation, lamination and accumulation during mixing. Mixing rate can reach over 99%. So far, this machine is one ideal mixer among all kinds of mixers. The loading capacity of barrel is good. it can reach 80%(40&%for normal ones).
Each part of drum is transited by circle arc and polished precisely, meeting the GMP requirements.This machine is used high homogeneity mixing of powdery and particle materials in such trades as pharmaceutical, food, chemical, light industry, machinery, electronics, mining and metallurgy, national defense industry and scientific research etc.
Application
pharmaceutical use mirror surface planet motion powder blender is widely applied in pharmaceutical, chemical, foodstuff, battery, plastics, metallurgy industries and research industries for homogeneous mixing.
Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
Working Principple
The barrel for charging the materials is driven by the driving shaft. The barrel body carries on the repeated level movement, rotation, turning and other complex movements so that the materials will carry out the three dimensions and complex movements along the barrel body so as to realize the various movements of the materials. Through disseminating, gathering, agglomerating and mixing to realize uniform mixing.
Technical Parameters
| Model Item | SYH-15 | SYH-50 | SYH-100 | SYH-200 | SYH-400 | SYH-600 | SYH-800 |
SYH- 1000 |
SYH- 1200 |
SYH- 1500 |
|
| Barrel capacity/L | 15 | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1500 | |
| Max loading capacity/L | 12 | 40 | 80 | 160 | 320 | 480 | 640 | 800 | 960 | 1200 | |
| Max loading weight/KG | 6 | 20 | 40 | 80 | 160 | 240 | 320 | 400 | 480 | 600 | |
| Speed of driving shaft/ R/min | 0~28 | 0~8 | |||||||||
| Motor power/kW | 0.37 | 1.1 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 7.5 | 11 | 11 | |
| Overall dimension/mm | L | 750 | 1400 | 1700 | 1800 | 2100 | 2400 | 2600 | 2650 | 2950 | 3100 |
| W | 1000 | 1000 | 1200 | 1400 | 1800 | 2200 | 2380 | 2500 | 2650 | 2850 | |
| H | 700 | 1200 | 1500 | 1600 | 1950 | 2350 | 2500 | 2600 | 2750 | 3000 | |
| Total weight/Kg | 200 | 300 | 500 | 800 | 1200 | 1500 | 2000 | 2500 | 3000 |
3500 |
|
