Place of Origin: | CHINA |
---|---|
Brand Name: | YIGAN |
Certification: | CE |
Model Number: | GZL |
Minimum Order Quantity: | 1 set |
Price: | negotiation |
Packaging Details: | Packed in film firstly, and then reinforced with wooden case for outer packing |
Delivery Time: | 20 working days after received your payment |
Supply Ability: | 10 sets per month |
Product Name: | Rolling Granulator/dry Granulator Machine | Application: | Industrial |
---|---|---|---|
Granules Shape: | Block Shape | Feature: | High Output |
Process Object: | Dry Powder | Standard: | CE/ROHS/FCC/SGS |
Highlight: | double roller granulator,roller compactor granulator |
GZL Series high output rolling granulator without any additive
Description
GZL Series high output rolling granulator without any additive can make the powder material become the granular solid. During the process, no additive
And mediate are added. After pelletizing, the grain size is even and bulk density increases. Meanwhile, it can control the pollution effecificy reduce the waste of power material. The design of it is scientific ,structure is compact, technological process is simple and operation is easy, it is an ideal for you to choose a pelletizing machine.
Working principle
Powder materials pass the vibrating material delivery bucket, after quanlity fixed by cross spiral material conveyor. Evenly enter main rolling flake material bucket, so quantity of material bucket keep constant .After powder material are precompressed by the longitudinal cone spiral in the main flake bucket, they will be sent to inlets of two curve slots. Half oblate eurve slots of rhomb slots or rhomb slots evenly separate on surface of two rollers. By way of enganing and transmission of a couple of geers, two rollers revolvein opposite direction with one speed. So materials are bitten into the slots and forced to be compressed in a twinkling. After materials being compressed and forming, the pressure on them gradually reduce, Materials drop by elasticity and gravity from the slots, enter the Broken Granulating System. There they are screened and graded according to consumer’s require of particle, size. Finally you get regular particle product conforming to quality standard. Rest of screened powder can return to vibrating bucket to be used again.
Features
Without any additive, dry powder be made to particles
Particle intensity can be adjusted, Regulate the pressure of rollers to control intensity of product.
Operating in cycles ,working continuously.
High product output, output of one machine can be than 2000kg/h(stocking intensity 1.5
Technical parameters
MODEL | GZL240 | GZL360 | GZL480 | GZL600 | |
Roller diameter mm | Ф 240 | Ф 360 | Ф 480 | Ф 600 | |
Width for use mm | 80 | 120-150 | 140-200 | 180-250 | |
Roller revolving speed rpm | 15~32 | 12~30 | 10~25 | 10~25 | |
Max forming pressure MPa | 12 | 16 | 21 | 30 | |
Max thickness of rolling mm | 4 | 8 | 8 | 8 | |
Output of rolling flake kg/h | 50~400 | 200~1600 | 450~3000 | 1000~6000 | |
Dia. of finshed granule mm | 0.5~6 | 0.5~6 | 0.5~6 | 0.5~6 | |
Output capacity kg | 30~180 | 120~800 | 280~1800 | 600~3000 | |
Power of main engine kw | 11 | 30 | 45 | 75 | |
Total power kw | 20 | 50 | 80 | 165 | |
Overall dimension (L×W×H mm3) |
1500×1500×2800 |
2000×2000×4500 |
2500×2500×5600 |
3200×3200×6300 |
|
Total weight t | 7 | 10 | 18 | 27 |
