| Place of Origin: | CHINA |
|---|---|
| Brand Name: | YIGAN |
| Certification: | CE |
| Model Number: | KJG |
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Packaging Details: | Packed in film firstly, and then reinforced with wooden case for outer packing |
| Delivery Time: | 20 working days after received your payment |
| Product Name: | Hollow Blade Dryer | Application: | Pigment Waste |
|---|---|---|---|
| Heating Mode: | Hollow Dryer | Heating Resource: | Steam,oil |
| Working Type: | Continuous | Model: | KJG-120 |
| Highlight: | industrial drying oven,rotary drum dryer |
||
KJZ-120 environmental non-standard hollow blade dryer for pigment waste
Continuous Industrial Drying Equipment Non Standard Hollow Blade Dryer For Pigment Waste KJZ-120
APPLICATION
KJZ-120 environmental non-standard hollow blade dryer for pigment waste is suitable for drying in plastic, resin, inorganic compounds machine, fertilizer, feed, dyestuff, starch, mud and so on.
DESCRIPTION
KJZ-120 environmental non-standard hollow blade dryer for pigment waste is low speed churned drier that equipped oars inside equipment. The damp raw material is churned to fully connect with hot carry and surface, its structure can be horizontal, double scrolls of force scrolls .
FEATURES
Compact structure, small volume, coefficient of thermal conductivity is high, best heat effect. In general heat effect attains to 80%-90%,it is kind of device with saving energy.
Low revolution, it is difficult to break into shaping of granule and slice raw material.
To raw material, wide use, easy to operate and raw material is adjustable from few minutes to few hours.
The auxiliary equipment is simple, so that it can save lots of cost.
There are multiple purpose such as drying, cooling, recovering air, responding heating…
WORKING PRINCIPLE
KJZ-120 environmental non-standard hollow blade dryer for pigment waste has a metal wall which separates the process mass from the heat source (steam or hot oil). High thermal efficiency is obtained because the heat from the thermal medium goes directly into the process mass. As the material comes into contact with the heated through and agitators, the process mass is heated via conduction. With an insulated dryer, very little heat is lost. To evaporate 1kg of water only requires about 1.2kg of steam for slurry materials. Exhaust gas is minimal and at a low temperature. Therefore, the volume of non-condensable gas from the dryer, which might require treatment, is minimal.
HEAT SOURCES(Temperature at 180℃ - 250℃)
Heating by Steam
Steam enters the hollow shaft through a rotary joint and is evenly distributed to all paddles. Condensate is removed with each revolution.
Heating by Hot Oil(thermal fluid)
Hot oil(thermal fluid) enters and exits the hollow shaft through a rotary joint. Pressure from the supply pump forces liquid through the hollow paddles.
Technical parameters
| Model | JYG3 | JYG9 | JYG13 | JYG18 | JYG29 | JYG41 | JYG52 | JYG68 | JYG81 | JYG95 | JYG110 |
| Heat area (m2) | 3 | 9 | 13 | 18 | 29 | 41 | 52 | 68 | 81 | 95 | 110 |
| effective volume(m3) | 0.06 | 0.32 | 0.59 | 1.09 | 1.85 | 2.8 | 3.96 | 5.21 | 6.43 | 8.07 | 9.46 |
| Speed range(rmp) | 15-30 | 10-25 | 10-25 | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 | 5-15 | 5-15 | 5-10 |
| power(kw) | 2.2 | 4 | 5.5 | 7.5 | 11 | 15 | 30 | 45 | 55 | 75 | 95 |
| widethA(mm) | 306 | 584 | 762 | 940 | 1118 | 1296 | 1476 | 1652 | 1828 | 2032 | 2210 |
| Total widethB(mm) | 736 | 841 | 1066 | 1320 | 1474 | 1676 | 1854 | 2134 | 1186 | 2438 | 2668 |
| lengthC(mm) | 1956 | 2820 | 3048 | 3328 | 4114 | 4724 | 5258 | 5842 | 6020 | 6124 | 6122 |
| Total lengthD(mm) | 2972 | 4876 | 5486 | 5918 | 6808 | 7570 | 8306 | 9296 | 9678 | 9704 | 9880 |
| Inport-outport distanceE(mm) | 1752 | 2540 | 2768 | 3048 | 3810 | 4420 | 4954 | 5384 | 5562 | 5664 | 5664 |
| Centre heightF(mm) | 380 | 380 | 534 | 610 | 762 | 915 | 1066 | 1220 | 1220 | 1220 | 1220 |
| Total height H(mm) | 762 | 838 | 1092 | 1270 | 1524 | 1778 | 2032 | 2362 | 2464 | 2566 | 2668 |
